A tension clamp and bracket set that connects ADSS cable to poles and towers. Preformed armour rods protect and cushion the cable so the clamp puts no undue stress on it. A single preformed-rod design, it suits short spans with low-tension ADSS cable.
Typical uses
Terminal poles, tension poles, continuation poles and line angles above 25°. Use 1 set per terminal pole and 2 sets per tension or continuation pole.
Construction
- Tension preformed rods: single layer, aluminium-clad steel
- Thimble: hot-dip galvanised steel
- Anchor shackle: hot-dip galvanised steel
Specifications
| Structure | Single-side bracket |
|---|---|
| Material | Aluminium, aluminium-clad steel (ACS) |
| Cable diameter | 11–16 mm; other sizes on request |
| Surface treatment | Hot-dip galvanised |
| Colour | Silver |
Packing
Boxed, on pallets.
