An optical time domain reflectometer (OTDR) for testing and fault-finding fibre links. It sends short light pulses down the fibre and records the power and arrival time of light reflected and back-scattered along it, then plots returned power against distance.
The trace shows reflective events such as connectors and breaks, and non-reflective events such as splices and tight bends; the power difference between two points estimates the loss between them.
Features
- One-button automatic testing
- 1310/1550 nm or 1310/1550/1625 nm wavelengths
- In-service PON testing (PON models only)
- Short dead zone (8 m)
- Fast signal processing, test and analysis
- Stores up to 10000 traces
- High-contrast colour TFT LCD
- USB connection to a PC
- Detects live input laser signal and protects itself
- Built-in visual fault locator (VFL)
- PC trace software shows event details
Specifications
| Model | AOR500-S | AOR500-A | AOR500-B | AOR500-C | AOR500-PB (PC) |
|---|---|---|---|---|---|
| Dynamic Range* | 24dB / 22dB | 28dB / 26dB | 32dB / 30dB | 36dB / 34dB | PON Online OTDR |
| Max.Distance** | 80km | 100km | 120km | 140km | 120km or 140km |
| Wavelength | 1550/1310nm | 1550/1310nm | 1550/1310nm | 1550/1310nm | 1550/1310/1625nm |
| Event Dead Zone ** | 1.5m | ||||
| Attenuation Dead Zone | 8.0m | ||||
| Pulse Width | 10ns, 25ns, 50ns, 100ns, 250ns, 500ns, 1us, 2.5us, 5us,10us | ||||
| Distance uncertainty | ±(0.8m ± 0.001% * testing distance ± resolution) | ||||
| Loss Resolution | 0.001dB | ||||
| Min.Distance Resolution | 1m | ||||
| Connector | FC interchangeable adapter (optional: SC,ST,LC interchangeable adapters) | ||||
| VFL | 1mW | ||||
| Data Storage | > 10000 traces (standard 1GB SD card) | ||||
| Display | 3.5 inch TFT colour LCD | ||||
| Interface | USB | ||||
| Battery | Built-in rechargeable battery | ||||
| Working Time | >10 hrs (Bellcore TR-NWT-001138) | ||||
Packing
Boxed, on pallets.
