A hardened H-connector SC patch cord (drop jumper) compatible with Corning OptiTap. It gives a robust, sealed connection for FTTH: the SC connection sits inside a slim, sealed, threaded polymer housing that connects to a multiport terminal or an in-line extension receptacle.
Features
- Drop cable available in dielectric or toneable versions
- Cable suits aerial, direct-buried or duct installation
- Standard lengths in 15 ft steps from 90 to 180 ft (longer on request)
- Sealed connector housing plugs straight into external bulkhead adaptors on terminals or closures, so the terminal or closure does not need to be opened to install a drop
- SC connectors mate with a standard adaptor, giving a common FTTx interface
- Cuts drop installation time and the total installed cost of connectorisation, with good durability and reliability in the drop segment
Specifications
| Cable type | Flat cable |
|---|---|
| Cable structure | Uni-tube/loose tube |
| Application | Outdoor duct and conduit |
| Fibre options | ITU G652D, G657A, OM1, OM2, OM3, OM4 |
| Fibre count | 12 cores |
| Bend radius (during installation) | 20 × cable outside diameter |
| Strength member | Fibreglass-reinforced plastic (FRP) |
| Jacket | TPU/LSZH |
Packing
Boxed, on pallets.
