An outdoor splitter distribution closure for the final link of FTTH networks, especially on poles and walls. It sits between the optical node and the customer terminals and handles fibre storage, splitting and distribution.
Features
- PC housing
- Two-zone layout: splitters in the lower section, splicing above, for clear and easy fibre distribution
- Takes 2 × 1:8 or 1 × 1:16 PLC splitters (blockless, module, micro or cassette type)
- 16 drop cable entries (pre-connectorised cable) and 4 express/cascade cable entries
Typical uses
Aerial, wall and pole mounting in FTTx, access and broadband networks.
Specifications
| Capacity | 144 fibres (6 × 24-fibre splice trays); 16 SC adaptors |
|---|---|
| Splitters | 2 × 1:8 or 1 × 1:16 |
| Drop cable entries | 16 |
| Express/cascade cable entries | 4, Φ8–Φ16 mm |
| Size | 526 mm × Φ235 mm |
| Insulation resistance | >2×104 MΩ at 500 V |
| Operating temperature | -40℃ to +60℃ |
| Connector loss (insertion, repeatability, interchangeability) | ≤0.5 dB |
| Return loss | PC ≥45 dB, UPC ≥50 dB, APC ≥60 dB |
