Heat-shrink splice protection sleeves for fusion splices on FTTH drop cable. Each sleeve combines a cross-linked polyolefin heat-shrink tube, a hot-melt inner tube and a stainless steel strength needle.
Features
- Protects the fusion splice and restores its mechanical strength
- Easy to fit, reducing the risk of fibre damage during installation
- Clear tube so the splice can be inspected after shrinking
- Shrinks quickly from a minimum of 120℃
- Sealed construction resists temperature and humidity
Specifications
| Materials | Cross-linked polyolefin heat-shrink tube, hot-melt tube, stainless steel needle |
|---|---|
| Minimum shrink temperature | 120℃ |
| Operating temperature | -55°C to 100°C |
| Pack quantity | 50 pcs per pack |
Dimensions
| Type | Length of tube | Hot-melt tube | Steel needle | |||
|---|---|---|---|---|---|---|
| After recover | Length(mm) | Inside dia | Length(mm) | Inside dia | Length(mm) | |
| FTST1045 | 5.8 | 45 | 3.6 | 45 | 1.0 | 45 |
| FTST1060 | 5.8 | 60 | 3.6 | 60 | 1.0 | 60 |
Packing
Boxed, on pallets.
