A drop wire clamp for anchoring overhead FTTH drop cable to buildings, poles and equipment, indoors or outdoors. It has a stainless steel body and bail, and a perforated stainless steel shim that raises the holding load without the cable slipping or being damaged.
Features
- Stainless steel for long service life and good corrosion resistance
- Serrated shim grips the cable; dimpled shim protects the cable jacket
- Stainless steel bail fits drive hooks, pole brackets, FTTH brackets and other drop hardware on walls and poles
- High strength; abrasion and wear resistant
- Easy to install and remove; maintenance-free
Typical uses
Securing fibre optic and other drop cables; relieving strain on messenger wire; supporting telephone drop wire at span clamps, drive hooks and other drop attachments. 1 pair and 2 pair clamps support both ends of an aerial drop using one or two pair drop wire; 6 pair clamps suit six-pair fibre-reinforced drop wire.
Specifications
| Application cable | Type | MBL,Kn | Cable size | Weight |
| Drop Cable | ODWAC-22 | 1.2 | 12*6 | 0.044kg |
Packing
Boxed, on pallets.
